Feature description

Product features:    GPS+LBS+WiFi positioning multiple positioning function. IP67 dustproof and waterproof grade. 4G network-wide connectivity. Only Nano cards are supported.

Languages of watches: Chinese,English,español,Deutsch,türkiye,русский,français,italiana,Nederlands,Polski,čeština,Magyar,slovenský.

Main parameter

Watch weight 58g

Measure    50.5*41*16(H)mm

Monitor    1.54 inch IPS

Processor    ASR3603S

Touch screen    1.54-inch G+F capacitive touch screen

Battery capacity    650mAh

Frequency band    "FDD:

B1(2100)/B2(1900)/B3(1800)/B5(850)/B7(2600)/B8(900)/B20(800)

WCDMA:B1(2100)/B2(1900)/B5(850)/B8 (900)

GSM: Band  B2(1900)/B3(1800)/B5(850)/B8(900)"

Sheathing material    Environmentally friendly LDS material

Trumpet    609 cavity loudspeaker with high sound quality

Gravity sensor    Support

Camera    30W

I/O interface    Four-point magnetic attraction type

Feature description:

1. Time calibration    Time zone calibration:

In case of no positioning, RTC clock is used. After going online, the user can manually set the corresponding time zone through the APP to update the current time zone of the watch.

2. Tracking and positioning:    Hibernation default manual acquisition positioning    The default positioning mode of the device is sleep mode. When entering the map interface, the device will automatically update the location or the watch will immediately upload the current location once after the APP issues an immediate positioning command.

3. Fixed upload:    The positioning frequency (interval) is 10 minutes or 1 hour. The terminal will acquire the current position according to the currently set positioning interval and upload it to the data platform center. Users can set different positioning intervals through the APP according to their own needs (the shorter the positioning interval, the shorter the watch's standby time).

4. Alarm function:    Low electric alarm    When the battery is lower than 20%, it will alarm to the APP client.

5. Electronic fence alarm:    Supports setting an electronic fence for a circular area, and triggering a cross-boundary alarm when the watch leaves the preset area (the platform implements the relevant algorithm).

6. SOS call the police:    When the device is online normally, press and hold the switch/SOS key for 5 seconds to perform the SOS alarm function. When no one answers, the watch will make two rounds of distress calls to 3 emergency contacts. If any of the 3 emergency contacts answer, stop the circular dialing and send a help SMS to the 3 emergency contacts at the same time to get assistance quickly.

7. Communication function:    Video call    The video call function between the APP client and the watch can be implemented

Contacts    Add contacts in the APP (up to 15 contacts supported)

8. Dialing function:    Autonomous dialing interface (supports short numbers to dial each other, does not support setting mobile phone numbers to dial short numbers, because they are not a group)

9. Micro chat:    Through GPRS data transmission, there is about 15 seconds of voice intercom transmission

10. Detection function:    Heart rate blood pressure    PPG light sensing measurement technology

11. Measurement of body temperature:    Heat transfer technology (optional function)

12. Sleep monitoring:    App settings sleep status detection

13. Other functions:    Unlock password    Unlocking the password can protect the device information more safely.

14. Take a picture:    Support watch selfie or APP remote photo taking

15. Voice time:    Elderly people with poor eyesight can press the time key to know the time without looking at it.

16. Step counting:    The equipment can record the number of exercise steps of the day.

17. Sedentary reminder:    Turn on sedentary reminder, and the device will remind you to exercise.

18. Weather forecast:    Support viewing weather conditions

19. Refuse to answer calls from strangers:    Phone numbers other than the phone book cannot be dialed into the watch. [Except for VoIP]

20. Alarm clock:    The APP sends this command, and the watch will ring for one minute for easy searching. Press any key to stop ringing.

Remote shutdown    The watch can be turned off remotely through the APP (the watch can be turned off and reset after being turned on and working normally by pressing the power-on button for 10 seconds)

21. Remote monitoring:    Set the monitoring number. After monitoring is turned on, the watch actively dials the set number. The watch can't hear the sound of the mobile phone, and the mobile phone can monitor the watch.

22. Historical track:    View the 90-day historical track.

23. Multiple guardianship:    Support multi-person login APP viewing, the APP for Setracker2.

Electrical parameters    Battery capacity    650MA

Maximum working current    ~280mA

Charging current    300mA

Charging time    ~2H

Endurance    ~4 days or so (10 minutes/positioning interval)

Receiving frequency    1.57542GHz(L1)

Cold start time    ~30s (outdoor is empty)

Warm start time    < 15s (outdoor is empty)

Hot start time    < 2s (outdoor is empty)

Horizontal precision    5m (typical)

Speed accuracy    0.1m/s (typical)

Capture sensitivity    -148 dBm

Tracking sensitivity    -165 dBm

Network communication protocol    Tcp/ip protocol

*This smart bracelet is not a real medical device. Compared with medical devices, all health data may have a little error, which is for reference only.

Package Contents:

1. Smart watch*1

2. Magnetic charging cable (Pogo pin)*1

3. Original box*1

4. Manual *1
